| Specification |
d | L | Boring range |
Adapter size |
Insert holder |
Weight |
| DCK1-ABH19-M | 19 | 32.5 | 20-26 | DCK1 | AACC2026 ABCC2026 | 0.09 |
| DCK1-ABH19-L | 19 | 32.5 | 25-31 | DCK1 | AACC2531 ABCC2531 | 0.10 |
| DCK2-ABH25-M | 25 | 50.6 | 29-36 | DCK2 | AACC2936 ABCC2936 | 0.17 |
| DCK2-ABH25-L | 25 | 50.6 | 35-42 | DCK2 | AACC3542 ABCC3542 | 0.19 |
| DCK3-ABH32-M | 32 | 62.5 | 36-45 | DCK3 | AACC3645 ABCC3645 | 0.37 |
| DCK3-ABH32-L | 32 | 62.5 | 44-53 | DCK3 | AACC4453 ABCC4453 | 0.37 |
| DCK4-ABH40-M | 40 | 62.5 | 45-56 | DCK4 | AACC4556 ABCC4556 | 0.56 |
| DCK4-ABH40-L | 40 | 62.5 | 55-66 | DCK4 | AACC5566 ABCC5566 | 0.58 |
| DCK5-ABH50-M | 50 | 78.5 | 56-74 | DCK5 | AACC5674 ABCC5674 | 1.10 |
| DCK5-ABH50-L | 50 | 78.5 | 74-92 | DCK5 | AACC7492 ABCC7492 | 1.14 |
| DCK6-ABH63-M | 64 | 81.4 | 70-90 | DCK6 | AACC7090 ABCC7090 | 1.78 |
| DCK6-ABH63-L | 64 | 81.4 | 90-110 | DCK6 | AACC90110 ABCC2026 | 1.90 |
| DCK6-ABH80-M | 80 | 81.4 | 90-130 | DCK6 | AACC2026 ABCC90110 | 2.30 |
| DCK6-ABH80-L | 80 | 81.4 | 130-170 | DCK6 | AACC130170 ABCC130170 | 2.44 |
